XR-125A
125CC Manual Mid Sized Dirt Bike
Available Colors
The Coolster XR-125A is similar to the XR-125, except that it comes with an inverted fork assembly. This type of fork is catered to more advanced riders and will improve on the vehicle’s dexterity and maneuverability. The 125cc 4-stroke vehicle comes with a manual transmission and features a variety of colors.
For more information, please click the tabs, or click here to reach us directly.
Download XR-125A Manual
(Must be logged in to download)
| Model Number: | XR-125A |
| Engine Type: | 124CC Single cylinder, 4-stroke, air-cooled |
| Max Torque: | 8.6N.m/5,500r/min |
| Max Horsepower: | 5.5KW/7,500r/min |
| Bore Stroke: | 54x54mm |
| Ignition: | CDI |
| Starting System: | Kick Start |
| Clutch: | Automatic and/or Manual |
| Transmission: | Chain, Foot |
| Brakes Front/Rear: | Hub/hydraulic disc |
| Tires Front/Rear: | 2.75-14 / 3.00-12 |
| Fuel Capacity: | 3.5 L |
| Weight: | G.W./N.W :74.5KG /60.7KG |
| Wheelbase: | 1075mm |
| Dimensions: | 1610 x 720 x 1030mm |
| Height to Seat: | 780mm |
| Min. Ground Clearance: | 280mm |
Please read the owner’s manual and all on-product warnings. Dirt Bikes can be hazardous to operate. For operator’s safety, always wear a helmet, eye protection, and protective gear. Never carry a passenger. Never ride under the influence of drugs or alcohol. Never ride on public roads nor pavement. Be extra careful on difficult terrain. Never allow a child to operate a Dirt Bike without adult supervision.
