ATV-3050B
110CC Fully Automatic Junior Sized ATV
Available Colors
Our Coolster ATV-3050B all-terrain vehicle is designed specifically for off-road fun. Powered by a dependable 110CC 4-stroke, air cooled engine, the vehicle features durable double a-arms, shock-absorbent suspensions, and light handling. Perfect for beginners and younger riders. For more information, please click the tabs, or click here to reach us directly.
Download ATV-3050B Manual
(Must be logged in to download)
| Model Number: | ATV-3050B |
| Engine Type: | 110CC Single Cylinder, 4-Stroke |
| Displacement: | 107cc |
| Max Torque: | 6.9N.m/6,500 ± 500r/min (N.m/r/min) |
| Max Power: | 4.8kW/8,000 ± 500r/min (kW/r/min) |
| Bore Stroke: | 52.4 x 49.5mm |
| Ignition: | CDI |
| Starting System: | Electric |
| Battery: | 12V, 4Ah |
| Clutch: | Automatic |
| Transmission: | Chain, Rear Wheel Drive |
| Brakes Front/Rear: | Drum/Hydraulic Disc |
| Tires Front/Rear: | 16 x 8-7 /16 x 8-7 |
| Fuel Capacity: | 0.54 gallons / 2.06L |
| Weight: | G.W./N.W154 lbs/176 lbs |
| Max Load: | 145 lbs / 65 kg (rider, all cargo and accessories) |
| Wheelbase: | 860mm |
| Dimensions: | 1,275 x 930 x 900mm |
| Height to Seat: | 440mm |
| Min. Ground Clearance: | 85 mm |
| Image | Name | Price | Buy |
|---|
Please read the owner’s manual and all on-product warnings. ATVs can be hazardous to operate. For operator’s safety, always wear a helmet, eye protection, and protective gear. Never carry a passenger. Never ride under the influence of drugs nor alcohol. Never ride on public roads nor pavement. Be extra careful on difficult terrain. Never allow a child under the age of 16 to operate an ATV without adult supervision. It is strongly recommended that all ATV riders take a training course. For more information, contact your local dealer or call 1-626-228-0251
